Canon Plxma G1020 Printer

Printer Specifications

Ink System

• Number of Nozzles: 1,792 total
• Ink Bottles (Type / Colors):
  • GI-71: Pigment Ink (Black)
  • Dye-Based Ink: Cyan, Magenta, Yellow
• Maintenance Cartridge: MC-G02

Printing Performance

• Maximum Printing Resolution: 4,800 (horizontal) × 1,200 (vertical) dpi
• Print Speed (ISO/IEC 24734):
  • Documents (ESAT/Simplex): 9.1 ipm (mono) / 5 ipm (color)
  • First Page Out Time (FPOT, Ready/Simplex): 9 sec (mono) / 16 sec (color)
  • Photo (4″ × 6″, PP-201, Borderless): 45 sec

Printable Area

• Printable Width: Up to 203.2 mm (8″)
  • Borderless: Up to 216 mm (8.5″)
• Borderless Printing: 0 mm margins on all sides
• Bordered Printing:
  • LTR/LGL:
    • Top margin: 3 mm
    • Bottom margin: 5 mm
    • Left margin: 6.4 mm
    • Right margin: 6.3 mm
  • Others:
    • Top margin: 3 mm
    • Bottom margin: 5 mm
    • Left/Right margin: 3.4 mm

Paper Handling

• Supported Media (Rear Tray):
  • Plain Paper (64 – 105 g/m²)
  • Photo Paper Pro Luster (LU-101)
  • Photo Paper Plus Glossy II (PP-201 / PP-208)
  • Matte Photo Paper (MP-101)
  • Double-Sided Matte Paper (MP-101D)
  • High-Resolution Paper (HR-101N)
  • Photo Paper Plus Semi-Gloss (SG-201)
  • Photo Stickers (PS-208 / PS-808)
  • Envelopes
• Paper Sizes (Rear Tray):
  • A4, LTR, LGL, 4″ × 6″
  • Custom Size: Width: 101.6 – 216 mm, Length: 152.4 – 1200 mm
  • F4 possible via custom size settings
• Borderless Paper Sizes: A4, LTR, 4″ × 6″
• Maximum Paper Capacity (Rear Tray):
  • Plain Paper (A4, 64 g/m²) / LTR: 100 sheets
  • High-Resolution Paper (HR-101N, A4): 80 sheets
  • Photo Paper Plus Glossy (PP-201, 4″ × 6″): 20 sheets
  • Photo Paper Plus Semi-Gloss (SG-201, 4″ × 6″): 20 sheets
  • Matte Photo Paper (MP-101, 4″ × 6″): 20 sheets
• Paper Weight (Rear Tray):
  • Plain Paper: 64 – 105 g/m²
  • Canon Paper Maximum Weight: Approx. 275 g/m² (Photo Paper Plus Glossy II, PP-201)

Print Head & Alignment

• Ink End Sensor: Dot count type
• Print Head Alignment: Manual

System Requirements

• Supported Operating Systems:
  • Windows 10 / 8.1 / 7 SP1 (only guaranteed on PCs with pre-installed Windows 7 or later)
  • macOS 10.12.6 ~ 10.15
  • Chrome OS

Connectivity & Power

• Interface: USB 2.0
• Power Requirements: AC 100-240V, 50/60Hz
• Power Consumption:
  • OFF Mode: 0.2W
  • Standby (USB to PC): 0.6W
  • Printing (USB to PC): 15W

Environmental Conditions

• Operating Environment:
  • Temperature: 5 – 35°C
  • Humidity: 10 – 90% RH (no dew condensation)
• Recommended Environment:
  • Temperature: 15 – 30°C
  • Humidity: 10 – 80% RH (no dew condensation)
• Storage Environment:
  • Temperature: 0 – 40°C
  • Humidity: 5 – 95% RH (no dew condensation)

Noise & Duty Cycle

• Quiet Mode: Available
• Acoustic Noise (PC Print, Plain Paper A4, B/W): 49.5 dB(A)
• Monthly Duty Cycle: Up to 3,000 pages

Physical Dimensions & Weight

• Factory Configuration: 445 × 330 × 135 mm
• Output/ADF Trays Extended: 445 × 564 × 249 mm
• Weight: Approx. 4.8 kg

Page Yield (ISO/IEC 24712 Test File)

• Plain Paper (A4):
  • Standard Yield:
    • GI-71 PGBK: 6,000 pages
    • GI-71 C, M, Y: 7,700 pages
    • GI-71S PGBK: 3,100 pages
    • GI-71S C, M, Y: 4,400 pages
  • Economy Mode Yield:
    • GI-71 PGBK: 7,600 pages
    • GI-71 C, M, Y: 8,100 pages
    • GI-71S PGBK: 3,900 pages
    • GI-71S C, M, Y: 4,600 pages
• Photo Paper (PP-201, 4″ × 6″) (ISO/IEC 29103 Test File):
  • Standard Yield:
    • GI-71 C, M, Y: 2,200 pages
    • GI-71S C, M, Y: 1,200 pages
  • PGBK Ink Usage for Photo Printing: Not Applicable
