Description
Key Specifications
-
Projection technology: 3LCD (RGB liquid‑crystal shutter)
-
Native resolution: WXGA (1,280 × 800), aspect ratio 16:10
-
Brightness: 4,000 ANSI lumens (white & colour) in normal mode; about 2,800 lumens in Eco/extended mode
-
Contrast ratio: Over ~2,500,000 :1 (some sources list over 5,000,000 :1)
-
Light source: Laser diode, lamp‑free design, rated for about ~20,000 hours (normal) and up to ~30,000 hours (eco/quiet)
-
Throw ratio (short‑throw lens): 0.48 – 0.65 :1
-
Projection screen size support: From ~53″ (1.35 m) to ~120″ (3.05 m) diagonally in typical use.
-
Keystone correction: Vertical ±15°, Horizontal ±15° (manual/hybrid)
-
Dimensions: approx 325 × 337 × 90 mm (W × D × H)
-
Weight: approx 4.6 kg
-
Built‑in speaker: 16 W mono
-
Connectivity highlights:
-
2× HDMI (HDCP 2.2)
-
2× VGA input, 1× VGA output
-
USB Type‑A (for media/USB power) and USB Type‑B (service)
-
Wired LAN (RJ‑45) + built‑in wireless LAN (WiFi) and Miracast support for screen‑mirroring/multi‑device display.
-
-
Power consumption: ~201 W (normal mode), ~144 W (eco mode), max ~260 W peak.
-
Noise level: ~37 dB(A) in normal mode, ~27 dB(A) in economy mode.
